The Dell Precision workstation graphics program is designed to provide customers with lifecycle and image stability from entry Professional 2D thru the Mid-Range 3D graphics cards.
Fully Buffered FB-DIMM ECC Registered Memory. As of this writing a 32GB kit is about $36 eBay item #292647079169. Up to 16 DIMM slots (1KW chassis required for memory expansion greater than 32GB and greater than 8 DIMM slots)įrom what I've read some RAM does not work in this system, it should take the following spec, it may be best to search eBay for a 690 compatible set. (512MB, 1GB, 2GB or 4GB DIMMS 512MB 533MHz DIMM not available on the 1KW chassis) Up to 64GB quad-channel architecture DDR2 Fully-Buffered DIMM 533 and 667MHz ECC memory Memory scalability up to 64GB with new DDR2 fully-buffered ECC DIMMs. Up to 5X more memory bandwidth with quad-channel memory architecture over the previous generation platform. With FB-DIMMs, you get DDR2 technology with a new, higher performance and more reliable, bidirectional serial bus which passes sequentially through every module. Quad-Channel DDR2 Full Buffered DIMM MemoryįB-DIMMs are an improved implementation of the current DDR2 standard for memory. Search for IEC320 Male C19 to Female C14 on eBay to find the proper adapter for your needs. Plug Socket Museum shows various connector types: It requires a C19 to mains or C19 to C14 adapter. The 1000W power supply has a rectantular C20 Inlet (male) connector. There is one USB port on the motherboard which uses the FlexBay pinout which is a single USB header, see the diagram at the bottom. Microphone and headphone connector (on front panel). 2 serial, 1 parallel, 2 PS/2, 1 RJ-45, Stereo line-in and headphone line-out (on back panel). 8 USB 2.0: two on front panel, five on back panel, one internal on motherboard. 1 external 3.5" flex bay for floppy or media card reader. 3 external 5.25" optical bays, one of which can accommodate a fifth HDD.
Option must be ordered at system purchase. Remaining slots are 2 PCI-X 64bit/100MHz and 1 PCI-e x8 slot wired as x4. NOTE: Graphics riser option covers up 2 PCI-e x8 slot wired as x4 and 1 PCI 32bit/33Mhz slot. 2 PCI-e x16 slots with optional graphics card riser on 690 1KW chassis.2 PCI-X 64bit/100MHz slots with support for 3.3v or universal cards.You are welcome to reply with corrections and/or additions.
This is from information I compiled over several days of my own research. Notes for the Dell 690, accuracy is not guarnteed.
